Devinci Milano Disc Stepthru Altus 8S

Devinci Milano Disc Stepthru Altus 8S
$939.00
Color:
Black Edition
Please select options
This item is exclusively available for IN-STORE PICKUP. Please wait for our order desk to confirm the item is ready and waiting for you at your chosen pick-up location.

Details

TIME YOUR PERFECT RIDE

Trading a gas pedal past for a cleaner, powered-by-you future was the inspiration behind Devinci's Leisure Series lineup. That and-of course-making everyday outings even more fun. Optimum GO2 builds bring reliability and confidence-inspiring features to casual countryside excursions or mandatory mid-town romps. Rear rack, fender, and kickstand compatibility enhance versatility across all models. And final-touch details such as a premium finish bolstered by clean, internal cable routing bring it all home in a sleek, stylish package. Your perfect ride starts here.

Geometry Chart:
SizeX-SmallSmallMediumLargeX-Large
ST (mm) 375 400 450 500 550
SA 74° 73° 73° 73° 73°
HA 70° 70° 70° 70° 70°
TT (mm) 545 555 570 585 600
REACH (mm) 379 378 390 396 406
CS (mm) 435 435 435 435 435
WB (mm) 1037 1036 1052 1068 1085
BBH (mm) 282 282 282 282 282
SOH (mm) 638 652 683 720 759
STACK (mm) 580 580 589 617 633
HT (mm) 90 90 100 130 150
Sizes:
SizeRider Height (cm)
X-Small 147-160
Small 152-171
Medium 169-180
Large 178-187
X-Large 185-193

Specs

Frame Aluminum Optimum G02
Fork SR Suntour NEX E25 HLO-DS | 75mm
Rims V2 Comp db | 18mm inner
Hubs Front: Formula Disc | QR 9x100mm
Rear: Formula Disc | QR 10x135mm
Spokes Stainless 14G
Tires Kenda K1170 | 700x38c
Crankset Alloy | 36T
Shifters Shimano M315 | 8s
Rear Derailleur Shimano Altus M370 | 8s
Cassette/Freewheel Sunrace | 8s | 11-40T
Chain KMC Z | 8s
Brakes Tektro HD-M285 | Hydraulic
Rotors Stainless | 160mm
Handlebars Devinci | B:25.4mm | R:20mm | W:640mm
Tape/Grips Devinci Ergo Comfort
Stem Devinci Adjustable | B:25.4mm | 0-60°
Headset Upper: FSA No.28 EC | Lower: FSA IS-3 IS
Seatpost Suspension Post | 27.2mm
Saddle Devinci
Pedals Wellgo C246

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Black Edition / X-Small 883385215517 FV22070111
Black Edition / Small 883385209516 FV22070211 210000117269
Black Edition / Medium 883385207222 FV22070311 210000117281
Black Edition / Large 883385209523 FV22070411 210000117294
Black Edition / X-Large 883385215524 FV22070511
